Composite Geomembrane

Compared with the traditional cloth and membrane separation, the use of composite geomembrane improves the use effect, saves the project time, reduces the project cost, and the comprehensive benefits are obvious.

Commodity name： Composite Geomembrane

Category:

WeChat

Keyword:

Composite Geomembrane

PRODUCT DESCRIPTION

Composite Geomembrane is a remarkable material that offers a wide range of benefits and applications. It is a combination of different materials, typically including a polymer film and a reinforcing fabric or layer.
This geomembrane is highly resistant to various factors such as water, chemicals, and UV radiation. It provides an effective barrier that prevents the passage of liquids and gases, making it ideal for applications like landfill liners, reservoir linings, and wastewater treatment facilities.
The reinforcing component of the composite geomembrane adds strength and durability. It helps to resist punctures, tears, and other forms of physical damage, ensuring long-term performance. The combination of the polymer film and the reinforcement creates a material that is both flexible and tough.
Installation of Composite Geomembrane is relatively straightforward, and it can be customized to fit specific project requirements. It can be laid smoothly and securely to form a continuous and impermeable barrier.
In addition to its primary function as a barrier, Composite Geomembrane also offers good chemical compatibility, allowing it to be used in environments with different chemical compositions. It is also resistant to microbial growth and degradation.
Overall, Composite Geomembrane is a reliable and essential material in various engineering and construction projects. Its unique properties make it a preferred choice for protecting the environment, preventing leaks, and ensuring the integrity of structures. It provides a cost-effective and sustainable solution for a wide range of applications where a high-quality and durable barrier is required.

Product Introduction
The composite geomembrane is divided into one cloth and one membrane and two cloth and one membrane, and the composite geomembrane can meet the needs of civil engineering such as anti-seepage, isolation, reinforcement and anti-cracking reinforcement in the construction of water conservancy, municipal, construction, transportation, subway, tunnel and other projects. Due to the selection of polymer materials and the addition of anti-aging agents in the production process, it can be used in unconventional temperature environments.
Features:
1. The width can reach six meters, compared with similar products with narrow width, it reduces the joints, reduces the project cost, shortens the construction period, and also reduces the hidden dangers caused by improper joint treatment.
2. Compared with the traditional cloth and membrane separation, the use of composite geomembrane improves the use effect, saves the project time, reduces the project cost, and the comprehensive benefits are obvious.
3. Good anti-aging performance. If it is buried and laid, the service life is longer.
Scope of application
1. Environmental protection and sanitation projects (such as domestic waste landfills, sewage treatment plants, toxic and harmful substances treatment sites).
2. Water conservancy and civil engineering (anti-seepage, plugging, reinforcement, seepage prevention and slope protection of canals, rivers, lakes, reservoirs and dams).
3. Municipal engineering (subway, underground engineering of buildings and roof reservoirs, roof garden seepage prevention, sewage pipe lining).
4. Landscaping (artificial lakes, ponds, pond lining, slope protection, etc.) of golf courses.
5. Traffic facilities engineering (foundation reinforcement of highways, seepage prevention of culverts).

Parameter

Mass per unit area (g/m²)		400	500	600	700	800	900	1000
commonly used specification	One cloth and one film	150/0.25	200/0.3	300/0.3	300/0.4	300/0.5	300/0.5	00/0.6
commonly used specification	Two cloths and one film	100/0.2/100	100/0.3/100	150/0.3/150	200/0.3/200	200/0.4/200	200/0.5/200	250/0.5/250
Breaking strength KN/m≥		5.0	7.5	10.0	12.0	14.0	16.0	18.0
Elongation at break %		30-100
Tear strong KN ≥		0.15	0.25	0.32	0.40	0.48	0.56	0.62
CBR Breaking Strength		1.1	1.5	1.9	2.2	2.5	2.8	3.0
Vertical permeability coefficient cm/s		10¹²
Hydrostatic pressure resistant to MpaKN≥		0.4-0.6			0.6-10
illustrate		Special specifications, can be customized according to customer technical requirements

Factory appearance

Shandong Xinying New Materials Co., Ltd. will be strong economic and technical strength, excellent product quality, casting China geo building materials new brand new image.
